Portable Spectrum Analyzer with Antenna SMA Male to UHF Female Cables & 30db Attenuator, 0.1MHZ-960MHz 2.8'' Touchscreen J15094
Sale price
$21.50
Regular price $83.94
Skip to product information
[2022 Upgraded Version: ESD Protection Diodes] Produced by Hugen, portable spectrum analyzer with latest firmware V0.3.1, the displayed version info is 'ESD protected' meaning the diodes are installed which will be more stable and sensitive with higher antistatic level and longer service life. NOTE: Due to the old inventory might mix with the new batch, and If you got the old version Tiny spectrum analyzer and want a new one, you could apply a replacement for it.
[Frequency Range] Spectrum analyzers like the Tiny spectrum analyzer use a resolution filter that is used to isolate the input power in a small frequency range. This resolution filter is swept across the desired frequency range. The fastest scanning speed occurs with an RBW or 300kHz or wider and is about 2 scans per second. But with increase of the frequency span and decrease of the RBW the scanning speed decreases quickly. A scan from 0MHz to 350MHz with an RBW of 10kHz takes about 2 minutes.
[2 in 1 Device] When not used as Spectrum Analyzer it can be used as Signal Generator, MF/HF/VHF sinus output between 0.1MHZ-350MHz, UHF square wave output between 240MHz-960MHz. Built-in calibration signal generator that is used for automatic self test and low input calibration. The Tiny spectrum analyzer contains all the components of a conventional heterodyne swept spectrum analyzer. Color display showing 290 scan points covering up to the full low or high frequency range
[PC Control] The USB interface implements the Serial over USB (CDC) protocol and there is a large set of commands that can be invoked over the serial interface. These command can be used to perform measurements or update internal settings. The driver for Windows will install automatically after connecting to a Windows PC. The driver for Linux is built into the kernel. Two softwares to control the Tiny spectrum analyzer are available.
[New Package Content] 1x Tiny Spectrum Antenna Analyzer; 2x SMA Male to UHF Female Cables 60cm/2Ft ; 1x 2W 30db SMA Attenuator ( if you need other attenuations, please inform us there are 3db, 6db,10db, 20db SMA attenuators for you to choose)
